Copper Wire Mesh

Copper wire mesh is pliable, malleable and featured with high thermal and electrical conductivity. It is no surprise that copper wire mesh becomes highly demanded option in the wire mesh industry. Copper wire mesh is ductile, malleable and has high thermal and electrical conductivity. As a result, it is popularly used as RFI shielding, in Faraday Cages, in roofing, in HVAC and in numerous electrical-based applications.


Copper wire cloth, brass wire mesh/ cloth, phosphor bronze wire/ cloth for sale. If you need custom copper wire cloth, please contact us for further negotiation.

Product Description


Detailed Information of Jiushen Copper Wire Mesh


Material: Brass (H65, H80), Red Copper, Phosphor Bronze (CSn6.50.4)

Standard: ASTM E2016-2020-5000 / ASTM E2814-2011

Weaving Pattern: Plain Weave, Twill Weave.

Features: Corrosion resistance, wear resistance, non-magnetic, good ductility

Application: Sieve grain, powder, porcelain clay, porcelain printing, shielding, filter gas and liquid etc.


Copper wire mesh is durable in many types of environments. Although it is softer than a similar stainless steel wire mesh, it is also resistant to atmospheric corrosion but attacked by oxidizing agents such as nitric acid, ferric chloride, cyanides, and ammonia acid compounds. copper wire mesh is made of 99.9% pure copper and when exposed to the atmosphere, will naturally develop a thin green layer, known as patina.


Copper wire mesh's unique color makes it a very popular option for many different types of users, including designers, artists, architects and home owners. Home owners and designers opt for copper wire mesh for residential projects including gutter guards, soffit screens, insect screen, fireplace screen, or even custom manufactured infill panels or decorative wall panels.


Without a doubt, copper wire mesh is critical to many industries, and it is often at the center of technological advancements in a broad range of fields. Over the past few years, customers have selected various copper mesh specifications for use in:


◆ Electric heaters

◆ Energy storage

◆ Pest control fumigation

◆ Robotics & power automation

◆ Metalsmithing & bookbinding

◆ Health, body and mind enrichment

◆ Air & liquid filtration and separation


Specification of Copper Wire Mesh


                      Copper Wire Mesh
Mesh(inch)Wire Dia.(mm)Aperture(mm)
140.451.37
160.41.19
180.40.99
200.40.87
300.30.55
360.250.46
400.220.415
450.160.4
500.20.3
600.160.25
800.120.2
1000.10.155
1500.060.11
2000.050.077
2500.040.062
Contact us for OEM details.


Jiushen Wire Weaving Co., Ltd. focus on manufacture and export of copper wire mesh for more than 20 years. With strong strength of research and development, Jiushen is able to provide you with copper wire mesh with best quality, application performance and low wholesale price directly from our factory in China. Our copper wire mesh will benefit you both in quality and before & after sales service. Contact us to get solutions from Jiushen to help you better in your projects!
