High Tensile Strength Stainless Steel Insect Screens is a kind of insect screen that developed by Jiushen as per the market demanding, which is woven by stainless steel wire of high tensile strength with finer openings.
High Tensile Strength Stainless Steel Insect Screens is a kind of insect screen that developed by Jiushen as per the market demanding, which is woven by stainless steel wire of high tensile strength with finer openings. The SS wire tensile strength is more than 1200N/mm2, after spraying with our patented powder coatings, the screen is particularly soft, which can greatly improve production efficiency and will never tear during installation. So many customers position this fly screen as a substitute for ordinary aluminum alloy insect screens and vigorously promote it in their market.
If you encounter any problem with your aluminum alloy insect screens, such as too stiff, tears too easily and the coating dropping off, please consider to try our insect screen, with the best quality second to none among all Chinese suppliers.
Wire tensile strength is more than 1200N/mm2
Very soft but do not tear at all
Extremely clear view
Good ventilation without shading
High mechanical protection performance
Corrosion resistance
Outstanding durability
Easy to maintain and clean
Ideal substitute for traditional aluminum alloy insect screens
Standards: Q/EQI-40-2007 ASTM B117-09 ASTM E2016-15
Weaving pattern: Plain weave folded edge / cut edge
Material: AISI 304,AISI 304L, AISI316, AISI 316L
| Item | High Tensile Strength Stainless Steel Window Screening |
| Material | AISI 304 |
| Specification | 20x18 / 0.11mm 22x22 / 0.09mm (can be customized) |
| Width | 610mm / 762mm / 810mm / 914mm / 1067mm / 1220mm / 1524mm / 1830mm (can be customized) |
| Length | 2m / 15m / 30m / 60m / 100m / 150m (can be customized) |
| Color | Black / Gray / Silver (can be customized) |
| Finish | Eco-friendly electrostatic coating |
| Opening | Square hole |
| Characteristics | High strength, high invisibility, high elasticity, soft, uniform opening, coating does not fall off, no fading within 10 years |
| Jiushen Window Screening Quality Characteristics | ||
| Item | Advantages | Control method |
| Flatness | No bubbling, arching | 1. Weaving process control 2. 100% leveling control of semi-finished products 3. 100% leveling control of finished product |
| Color | The surface color is consistent in all angles | 1. Special coating control 2. Coating thickness and uniformity control |
| Defect control | per 30㎡≤1 | 1. 100% inspection of semi-finished products 2. 100% inspection of finished products 3. Special production and correction equipment |
High Tensile Strength Stainless Steel Insect Screen
High Tensile Strength Stainless Steel Insect Screen
